    Discover the details making up the original design of the SGH circular connectors. See the overall dimensions and the videos showing the exploded views of all the components of the Syntax Gigamod Hybrid.

     Find out the details that make the difference

  • SGH 8.1
    inline version

    SGH 8.1
    inline version

    8 modules + power or signals

    8 modules + power or signals

  • Exploded view

    Exploded view

     Exploded view
    Click here to watch the video

  • Overall dimensions

    Overall dimensions
  • Inline female

    Inline female

    Inline female

    SGH 8.1 | M32 cable gland for single cable

    SGH 8.1 | M32 cable gland for single cable

    Dimensions in mm
  • Inline male

    Inline male

    Inline male

    SGH 8.1 | M32 cable gland for single cable

    SGH 8.1 | M32 cable gland for single cable

    Dimensions in mm
  • Inline female

    Inline female

    Inline female

    SGH 8.1 | M40 cable gland with multiway grommet
    for cable splitters

    SGH 8.1 | M40 cable gland with multiway grommet
    for cable splitters

    Dimensions in mm
  • Inline male

    Inline male

    Inline male

    SGH 8.1 | M40 cable gland with multiway grommet
    for cable splitters

    SGH 8.1 | M40 cable gland with multiway grommet
    for cable splitters

    Dimensions in mm

  • | pictured: 2Lan + power 16amp |

    | pictured: 2Lan + power 16amp |

    More info about SGH 8.1 inline

  • SGH 8.1
    panel version

    SGH 8.1
    panel version

    8 modules + power or signals

    8 modules + power or signals

  • Exploded view

    Exploded view

     Exploded view
    Click here to watch the video

  • Overall dimensions

    Overall dimensions
  • Panel female

    Panel female

    Panel female

    SGH 8.1

    SGH 8.1

    Dimensions in mm
  • Panel male

    Panel male

    Panel male

    SGH 8.1

    SGH 8.1

    Dimensions in mm
  • Cut-out dimensions

    Cut-out dimensions

    Cut-out dimensions

    SGH 8.1

    SGH 8.1

    Dimensions in mm

  • | pictured: 2Lan + power 16amp 5p |

    | pictured: 2Lan + power 16amp 5p |

    More info about SGH 8.1 panel

  • SGH 16.1
    inline version

    SGH 16.1
    inline version

    16 modules + power or signals

    16 modules + power or signals

  • Exploded view

    Exploded view

     Exploded view
    Click here to watch the video

  • Overall dimensions

    Overall dimensions
  • Inline and Multiway female

    Inline and Multiway female

    Inline and Multiway female

    SGH 16.1

    SGH 16.1

    with standard backshell and cable gland.
    Dimensions in mm
  • Inline and Multiway male

    Inline and Multiway male

    Inline and Multiway male

    SGH 16.1

    SGH 16.1

    with standard backshell and cable gland.
    Dimensions in mm

  • | pictured: 4Lan + power 32amp |

    | pictured: 4Lan + power 32amp |

    More info about SGH 16.1 inline

  • SGH 16.1
    panel version

    SGH 16.1
    panel version

    16 modules + power or signals

    16 modules + power or signals

  • Exploded view

    Exploded view

     Exploded view
    Click here to watch the video

  • Overall dimensions

    Overall dimensions
  • Panel female

    Panel female

    Panel female

    SGH 16.1

    SGH 16.1

    Dimensions in mm
  • Panel male

    Panel male

    Panel male

    SGH 16.1

    SGH 16.1

    Dimensions in mm
  • Cut-out dimensions

    Cut-out dimensions

    Cut-out dimensions

    SGH 16.1

    SGH 16.1

    Dimensions in mm

  • | pictured: 4Lan + power 32amp |

    | pictured: 4Lan + power 32amp |

    More info about SGH 16.1 panel
